BrillLas-mHz Series is a highly-reliable millihertz-linewidth single-frequency laser, achieving <10 mHz Lorentzian linewidth and <25 MHz/day long-term frequency drift.
Based on high quality laser cavity and nonlinear optical linewidth compression, BrillLas-mHz delivers world-class ultra-low-noise performance for quantum metrology, optical sensing, and mmWave/THz systems.
BrillLas-mHz 是一款款高可靠性毫赫兹线宽激光器，基于高品质激光谐振腔与非线性噪声压缩技术，实现 ≤10mHz 洛伦兹线宽与日频率漂移 ≤25 MHz。
| Wavelengths Offered | 1550 ± 30 nm (Optional: 1064nm/1310nm/1610nm) |
|---|---|
| Spectral Linewidth | ≤ 10mHz, Lorentzian; Instantaneous |
| Output Power | ≥ 5 mW (Optional: > 1W) |
| Frequency Noise | 10 Hz/√Hz @ 1 kHz offset 2 Hz/√Hz @ 1 MHz offset |
| Short Term Stability (Typical) | ≤ 5×10^-11 @ 1 s |
| Frequency drift (Typical) | ≤ 25 MHz/day (选项: ≤ 1MHz/day) |
| Side-Mode Suppression Ratio | ≥ 60 dB |
| Relative Intensity Noise | ≤ -130 dBc/Hz |
| Operating Temperature | +20°C to +40°C, Case temperature |
Applications: Quantum precision measurement, optical fiber sensing, coherent communications, mmWave/THz photonic generation, and fundamental physics experiments requiring ultra-stable optical references.
