BrillLas-OFD

BrillLas-OFD Series is a high-performance optical frequency division system, achieving phase noise floor ≤ -150 dBc/Hz @10 kHz offset and fractional frequency instability ≤ 5e-13.

Based on advanced frequency stabilization and phase-locked loop technologies, BrillLas-OFD provides ultra-precise optical frequency synthesis and division for quantum computing, precision spectroscopy, and next-generation timing applications.

BrillLas-OFD 是基于先进的超稳激光技术与光电融合锁相环技术开发的高性能光学分频微波信号源，实现10GHz载波相位噪声基底 ≤-150 dBc/Hz @10 kHz频偏和频率不稳定度 ≤5e-13。

Key Specifications

Frequency 10 GHz~ 100 GHz (single frequency; synthesizer optional)
Output Power 5 mW (Optional ≥ 50 mW)
Phase Noise Floor ≤ -150 dBc/Hz @10 kHz offset (10 GHz carrier)
Fractional Frequency Instability ≤ 5e-13@1s
OFD Diagram 1

Applications: Ultra-precise timing and synchronization, quantum computing, precision spectroscopy, optical clock networks, metrology, and fundamental physics research requiring extraordinary frequency stability.

Nonlinear Optics Laboratory, University of Electronic Science and Technology of China (UESTC)
